Our HDPE Double Wall Corrugated Pipe represents the ideal solution for modern drainage systems and cable protection applications. Combining structural strength with hydraulic efficiency, this innovative pipe features a unique dual-wall construction with a smooth inner wall for excellent flow characteristics and a corrugated outer wall that provides exceptional ring stiffness and impact resistance.

Share:

Introduction

Our HDPE Double Wall Corrugated Pipe represents the ideal solution for modern drainage systems and cable protection applications. Combining structural strength with hydraulic efficiency, this innovative pipe features a unique dual-wall construction with a smooth inner wall for excellent flow characteristics and a corrugated outer wall that provides exceptional ring stiffness and impact resistance.

Manufactured from high-grade polyethylene materials, our pipes offer superior resistance to corrosion, abrasion, and chemical degradation, ensuring long-term performance in even the most demanding environments. The lightweight nature of HDPE facilitates easy handling and installation, significantly reducing project timelines and labor costs compared to traditional materials.

Available in various stiffness classes (SN4, SN8, SN16) and diameters ranging from 100mm to 1200mm, our double wall corrugated pipes are suitable for multiple applications including stormwater drainage, sewer systems, road construction, and underground cable protection.

Parameter

The Specification of HDPE Double-Wall Corrugated Pipe (mm)

DN/ID

Min ID

OD

O.D.tolerance

Min Thinkness

Bellmouth ID

Min Bellmouth ID

225

220

255

±3

≥1.7

264-269

≥55

300

294

330

±3

≥2.0

348-351

≥64

400

392

456

±3

≥2.5

465-469

≥74

500

490

572

±3

≥3.0

549-553

≥85

600

588

690

±3

≥3.5

668-672

≥96

800

785

925

±3

≥4.5

888-895

≥118

Application

  • Sewer and drainage
  • Frontage drains for terrace and other residential units in housing schemes
  • Perimeter drains for commercial, industrial units and individual factories
  • As collector drains in subsoil system in road, highway, open field, stadium,retaining wall or parking space
  • As collector drains in subsoil system, sewerage treatment plant sludge drying bed under drains
