01 In accordance with the norms of DIN 8077/8078.
02. With the exceptional heat stabilityand its corrosion resistant performance,this Plastic Pipe has become the most reliable plumbing system for hot and cold water applications with service lifein excessof 50 years.
The raw material of PPR pipe is polypropylene, which is non-toxic and tasteless, and can be used in pure water drinking pipeline system.
No rust and corrosion, making the water delivered cleaner and more hygienic.
The service life of the pipeline system is 50 years under normal use.
Beautiful appearance, smooth inner and outer walls, soft color.
Light weight, high strength and good toughness.
The melting point temperature of relatively pure PPR raw material is 220℃, the working water temperature of PPR pipe is 95℃,and the short-term use temperature can reach 120℃, under the condition of temperatureof 60℃ and working pressure of 1.2Mpa long-term continuous use.
|
Outer Diameter(mm) |
Wall thickness(mm) |
|||
|
|
S5,PN10,1.25MPa (Cold water) |
S4,PN16,1.6MPa (Cold water) |
S3.2,PN20，2.0MPa (Hot water) |
S2.5,PN25，2.5MPa (Hot water) |
|
20 |
2.0 |
2.3 |
2.8 |
3.4 |
|
25 |
2.3 |
2.8 |
3.5 |
4.2 |
|
32 |
2.9 |
3.6 |
4.4 |
5.4 |
|
40 |
3.7 |
4.5 |
5.5 |
6.7 |
|
50 |
4.6 |
5.6 |
6.9 |
8.3 |
|
63 |
5.8 |
7.1 |
8.6 |
10.5 |
|
75 |
6.8 |
8.4 |
10.3 |
12.5 |
|
90 |
8.2 |
10.1 |
12.3 |
15.0 |
|
110 |
10.0 |
12.3 |
15.1 |
18.3 |
|
25 |
11.4 |
14.0 |
17.1 |
20.8 |
|
140 |
12.7 |
15.7 |
19.2 |
23.3 |
|
160 |
14.6 |
17.9 |
21.9 |
26.6 |
|
200 |
18.2 |
22.2 |
27.9 |
33.3 |
