HDPE pipe is produced by high density polyethylene raw material. Uses in gaseous fuels, municipal, marine, mining, storage, canal and industrial area. HDPE pipe is strong, Environmentally, flexible and lightweight. It is the best choice with its high quality, lower cost and performance..High density polyethylene pipes resist to corrosion, abrasion and high resistance to chemical resistance. HDPE pipes with 50 years life long term being produced by CHUANGRONG based in China and are shipped more than 60 countries in the world.
HDPE pipe is produced by high density polyethylene raw material. Uses in gaseous fuels, municipal, marine, mining, storage, canal and industrial area. HDPE pipe is strong, Environmentally, flexible and lightweight. It is the best choice with its high quality, lower cost and performance..High density polyethylene pipes resist to corrosion, abrasion and high resistance to chemical resistance. HDPE pipes with 50 years life long term being produced by CHUANGRONG based in China and are shipped more than 60 countries in the world.
|
Product Name |
HDPE Gas Pipe |
|
Sizes Available |
DN 20 mm - 630mm, 1 inch - 25 inch |
|
SDR |
SDR17,SDR11, |
|
PN |
PN3,PN5,PN7 |
|
Material |
PE100 |
|
Executive Standard |
Executive Standard |
|
Colors Available |
Black color with orange strips |
|
Packing Method |
Normal export packing. |
|
Production Lead Time |
Depending on the order quantity. |
|
Certificate |
ISO, CE |
|
Supply Ability |
100000 Ton/Year |
|
Payment Method |
T/T, L/C at sight |
|
Trading Method |
EXW, FOB, CFR, CIF |
|
20mm-630mm |
SDR17.6 |
SDR11 |
SDR9 |
|
20 |
2.3 |
3 |
3 |
|
25 |
2.3 |
3 |
3 |
|
32 |
2.3 |
3 |
3.6 |
|
40 |
2.3 |
3.7 |
4.5 |
|
50 |
2.9 |
4.6 |
5.6 |
|
63 |
3.6 |
5.8 |
7.1 |
|
75 |
4.3 |
6.8 |
8.4 |
|
90 |
5.2 |
8.2 |
10.1 |
|
110 |
6.3 |
10 |
12.3 |
|
125 |
7.1 |
11.4 |
14 |
|
140 |
8 |
12.7 |
15.7 |
|
160 |
9.1 |
14.6 |
17.9 |
|
180 |
10.3 |
16.4 |
20.1 |
|
200 |
11.4 |
18.2 |
22.4 |
|
225 |
12.8 |
20.5 |
25.2 |
|
250 |
14.2 |
22.7 |
27.9 |
|
280 |
15.9 |
25.4 |
31.3 |
|
315 |
17.9 |
28.6 |
35.2 |
|
355 |
20.2 |
32.3 |
39.7 |
|
400 |
22.8 |
36.4 |
44.7 |
|
450 |
25.6 |
40.9 |
50.3 |
|
500 |
28.4 |
45.5 |
55.8 |
|
560 |
31.9 |
50.9 |
62.5 |
|
630 |
35.8 |
57.3 |
70.3 |
This is the most common application. HDPE pipes are used as the main backbone for distributing natural gas from city gate stations to residential neighborhoods, commercial districts, and industrial areas. Their corrosion resistance ensures product purity and a long, maintenance-free service life underground.
HDPE pipes are used for the secondary mains running under streets and, most notably, for the direct service lines that connect individual homes, apartments, and businesses to the main gas grid. Their flexibility allows for trenchless installation, minimizing surface disruption.
Within industrial facilities, HDPE pipes safely transport natural gas as a fuel source for boilers, furnaces, and other processing equipment. Their safety and reliability are critical in these complex environments, reducing the risk of leaks compared to metallic alternatives.
HDPE is the preferred material for areas with corrosive soils, high water tables, or coastal regions with saltwater exposure, where steel pipes would rapidly corrode. Its durability also makes it suitable for installations in seismically active zones due to its ability to withstand ground movement.
HDPE pipes are increasingly used for transporting renewable gases, such as biogas from landfills or anaerobic digesters. They are also the leading material being tested and approved for use in hydrogen blending projects, positioning them as the pipeline for the future of clean energy.
